Beyma TD-WL4
90°x 20° Constant Directivity Line Array Horn
$ 1,200.00 TT
Price VAT Inclusive
Description
Specifications
Description
- BEYMA TD-WL4 IS A CONSTANT DIRECTIVITY HORN FOR LINE ARRAY SYSTEMS
- DESIGNED TO BE USED WITH (2) WL4 LINE ARRAY HIGH FREQUENCY DRIVERS
- 90° HORIZONTAL x 20° VERTICAL COVERAGE
- UNIFORM ON/OFF AXIS WITH A NATURAL FREQUENCY REPRODUCTION WITH PRECISE DIRECTIVITY CONTROL
- CAST ALUMINUM FOR SUPERIOR STRENGTH & FLAT FRONT TO FACILITATE FLUSH MOUNTING
Specifications
Type | Constant Directivity |
Throat Size | .47″ Wide X 8.19″ Height |
Dispersion | 90°x 20° |
Lowest Rec. Crossover | 800Hz |
| Directivity Factor | 60 |
| Directivity Index | 15.5 dB |
| Construction | Cast Aluminum |
Net Weight | 3.3 lbs. / 1.5kg. |
| Shipping Weight | 3.96 lbs. / 1.8kg. |
MOUNTING INFORMATION | |
| Overall Width | 8.26” / 210mm |
| Overall Height | 10.23” / 260mm |
| Overall Depth | 5.79” / 147mm |
| Cutout Width | 6.85″ / 174mm |
| Cutout Height | 9.72″ / 247mm |
| Mounting Type | Bolt On |
