Features:

• Front Auxiliary Input
• Subwoofer Level Control
• 3 Selectable Inputs Main/Aux
• Low-Level or Hi-Level Input
• Variable Low Pass Frequency Control

Specifications:

• Frequencies – 50Hz, 125Hz, 315Hz, 750Hz, 2.2kHz, 6kHz, 16kHz
• Boost/Cut – 12dB
• S/N Ratio – 83dB
• Frequency Response – 8Hz – 140kHz + /-1dB
• Maximum output voltage – 8V
• THD – 0.01%
• Input Sensitivity (RCA) – <3.6V
• Input Sensitivity (High) – <10.8V
• Input Impedance – 20K Ohms
• Output Impedance – 1K Ohms
• Stereo Separation – 73dB/1kHz
• Operating Voltage – 11V – 15V Negative Ground
• Size (WxDxH) – 7″ x 4 1/4″ x 1″
