Key Features

• All MOSFET Power Supply & Output Stage
• Heavy Gauge / High Current Custom Power and Speaker Terminals
• 12dB Octave Low-Pass FilterCapable of powering speakers at 4-ohm (500W), 2-ohm (780W), and 1-ohm (1250W) loads.
• Electronic Crossover Network
• Bass Boost Circuit
• Power and Protection LED Indicators
• Soft Turn-on/Turn-off Turn-On Delay
• Fault and Protection Monitoring
• 4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage

Power Output:

• 4-Ohms: 500 Watts
• 2-Ohms: 780 Watts
• 1-Ohm: 1250 Watts
• S/N: >90dB

Specifications

• Input Sensitivity: 522mV~6V
• Bass Boost: 0dB~12dB
• Subsonic Filter: 10Hz ~ 30Hz
• High Pass Filter: N/A
• Low Pass Filter: 50Hz ~ 250Hz
• Phase: 0~180 Degrees
• Remote Gain Control: Yes
• S/N: >90dB
• Damping: >200
• Recommended Fuse Rating: 150A
