480 RMS 2 Channel


Prices VAT Inclusive

The C Series Amplifiers offer the warm sound that Class AB amplifiers are known for, along with features such as band-passable crossover networks, high-end output devices, and set screw power and speaker terminals.

The chassis design features a single side control panel giving the C Series an elegant aesthetic and makes cable management and audio adjustments easy for quick clean installations.

The C series is offered in four power options giving system designers a high level of application flexibility.

C Series Design Features:

  • Mosfet Power Supply Amplifier
  • 4 Gauge Power Terminals
  • Conformal Coated PCB
  • Variable 12dB/Oct HPF and 18dB/Oct LPF Crossovers
  • Pass-Through Output
  • Remote Subwoofer Control (w/ DMRMT Sold Separately)
  • Input Mode Switch (C4.60, C4.100)
  • 4-Way Protection: Over Voltage, Short Circuit, Thermal, DC Offset
Test Voltage14.4V
Cont Wattage @ 4ohm150×2 / 480×1
Cont Wattage @ 2ohm175×2
Max Current Draw – Amperage50A
S/N Ratio>86dB
Input Voltage Sensitivity8V-0.25V
Pass-Through OutputYes
Remote Subwoofer ControlYes (sold separately)
Power Wire Guage In4
Speaker Wire Gauge Out12
Dimensions: in14x7x2
Dimensions: mm348x175x54
